Working principle:
It is a machine that is powered by a motor and is actuated by a T-type pump to transport grease through extrusion.
Advantage:
You can add butter even during work to improve work efficiency.
Equipped with an alarm for the lower limit of the oil level, it will alarm while the volume of grease is under limited line, to avoid grease cut-off protection.
The design of the oil dial can separate the oil from the air to ensure that the oil does not contain air during work.
Application fields:
✓ T / 3C
✓ Industrial automation
✓ Micro-motor
✓ Home furniture
✓ Automobile
✓ Aerospace
Specification:
| Electric butter machine | Model:HH-GD-F10-B |
| Voltage | Ac220V-2P or Ac380-3p |
| tank | 20L |
| Output | 0.5L per min |
| Lubricant | NGLI O#～3# |
| Pressure | 30kg/cm |
| Temp. | -10～50 |
| Dimension | 320*370*1140mm |
Post time: Mar-29-2023
