The specification of polishing wheel is ￠300*200mm (outer diameter*thickness), and the inner hole is designed to be ￠50mm. (Minimum size of polishing wheel ￠ 200)
When grinding and polishing, the grinding head can swing back and forth.
The service life of the abrasive belt can be visualized, and the wear of the polishing wheel is automatically compensated.
The equipment reserves 3 dust extraction ports, and is equipped with a dust collection bucket or a collection drawer to facilitate cleaning of the garbage inside the machine.
The spindle frequency conversion speed regulation.
Motor overload has protection function.
Adopt solid automatic waxing (wax loss can be automatically fed).
The working range of the workpiece is 90-250 mm in diameter and 380-1800 mm in length.
The jig with random belt.
Guide rail dust cover and automatic lubrication.
The polishing efficiency is about 1.5M/min
Equipped with two sets of workpiece telescopic brackets, which is convenient for lifting and lowering the motor tube
Polishing wheel clip ￠150
Benefits
The combinations of wheels are changeable according to different raw material & finish, it’s very flexible for wide application to cover future products.
The speed of rotary table & jigs are adjustable as well, it will effect the processing time, this is a real CNC smart with digital machinery.
There is a touch screen with friendly interface of system with editable for all those parameter settings, it will achieve whatever needed a perfect finish.
Not only above, there is a auto-waxing & swinging system are optional for a high quality achievement.
